Hush Beam™

Lets Do This > Visit SpecLink

Lamvin Is Reinventing Acoustical Design. Our revolutionary,Hushtone acoustical product line is a designer's dream. No stone was left unturned while curating this beautiful assortment of products. Our Hushtone line is made with the highest quality design-friendly felt, for the ultimate in aesthetics and acoustical benefit.



Specifications

  • Product Weight: 1.5 lbs/SF
  • Length: 4’, 8’
  • Width: 2.75’’
  • Height: 12’’, 16’’, 24”


Environmental Factors

  • 100% recyclable
  • Low VOC Emissions
  • ASTM - D5116
  • LEED - MRc4


Composition

  • 100% Polyethylene Terephthalate (PET)
  • 55% recycled content


Fire Rating

  • Class A per ASTM E-84, based on 9mm white
  • CAN/ULC S102 testing available upon request

  Downloads:

Brochure (2.2 MiB)

Data Sheet (487.2 KiB)

Color Chart (4.0 MiB)

Install-Drywall (698.9 KiB)

Install-Unistrut (699.1 KiB)

Material Specs (1.8 MiB)

Cleaning Guide (135.6 KiB)

Acoustical Data

Frequency (Hz) 125 250 500 1000 2000 4000 NRC
2.75 Thickness 0.53 0.74 1.06 1.54 1.77 1.94 1.30
Frequency (Hz) 125 250 500 1000 2000 4000 SABINS
2.75 Thickness 2.94 4.45 7.05 10.62 12.61 13.64

Based on Baffle size 4’ x 2’ with Type “J” Mounting. Sabins are based on Sabins per Object, NRC is an equivalent number based on one face of one panel
