Subway™

Lets Do This > Visit SpecLink

Noise transfer between interior offices can be a problem; our Subway wall tiles can solve these noise issues and provide aesthetic appeal to any space.



Specifications

  • Panel Sizes: 23.5” w x 23.5” h or 47” w x 23.5” h
  • Thickness: 9mm
  • Edge Detail: Chamfered
  • Weight: .25 lbs/SF


Environmental Factors

  • 100% recyclable
  • Low VOC Emissions
  • ASTM - D5116
  • LEED - MRc4


Composition

  • 100% Polyethylene Terephthalate (PET)
  • 55% recycled content


Fire Rating

  • Class A per ASTM E-84
  • CAN/ULC S102 testing available upon request

  Downloads:

Brochure (2.2 MiB)

Data Sheet (1.3 MiB)

Installation (304.9 KiB)

Color Chart (4.0 MiB)

Material Specs (1.8 MiB)

Cleaning Guide (135.6 KiB)

Acoustical Data

Frequency (Hz) 125 250 500 1000 2000 4000 NRC
9mm Thickness 0.04 0.04 0.16 0.40 0.63 0.82 0.30

Tested as Type "A" Mounting.
