Zeppelin™

Lets Do This > Download MasterSpec®

Lamvin Is Reinventing Acoustical Design. Our revolutionary, Hushtone acoustic product line is a designer's dream. No stone was left unturned while curating this beautiful assortment of products. Our Hushtone line is made with the highest quality design-friendly felt, for the ultimate in aesthetics and acoustical benefit.



Specifications

  • Standard Cloud Sizes: 47” Diameter Circle or 47” x 47” Square
  • Product Weight: 15 lbs/Cloud *weight without light
  • Thickness: 2.75’’


Environmental Factors

  • 100% recyclable
  • Low VOC Emissions
  • ASTM - D5116
  • LEED - MRc4


Composition

  • 100% Polyethylene Terephthalate (PET)
  • 55% recycled content


Fire Rating

  • Class A per ASTM E-84, based on 9mm white
  • CAN/ULC S102 testing available upon request

  Downloads:

Brochure (2.2 MiB)

Data Sheet (2.0 MiB)

Color Chart (2.5 MiB)

Installation (200.8 KiB)

Material Specs (1.8 MiB)

Cleaning Guide (135.6 KiB)

Acoustical Data

Frequency (Hz) 125 250 500 1000 2000 4000 NRC
2.75" Thickness 0.53 0.75 1.06 1.54 1.77 1.94 1.30

Based on Cloud size 4’ x 4’ with Type “J” Mounting. NRC is an equivalent number based on one face of one panel.
