Sound Sucker Panel®
Lets Do This > Download Revit File Download MasterSpec®
Sound Sucker Panels are specifically designed for the harshest environments. With strong galvanized facing, the Sound Sucker Metal Acoustical Panel provides industrial sound solutions for machine and equipment rooms where noise control is more than aesthetic comfort but essential to safety.
Specifications
- Custom shapes max size: 42" to 120"
- Thickness 2"
- Custom sizes also available
Composition
- 6-7 lb. density rigid fiberglass board
- Metal facing 18-24 gauge G-90 Galvanized .032 aluminum/stainless steel
- Flat or corrugated face
Finish
- Perforations 3/32” diameter on 5/32” staggered centers
- 33% open area (custom perforations available)
- Natural metal or powder coat finish
- Variety of colors available
Fire Rating
- All components are ASTM E84—Class I/A
Acoustical Data
| Frequency (Hz) | 125 | 250 | 500 | 1000 | 2000 | 4000 | NRC |
|---|---|---|---|---|---|---|---|
| 2" Thickness | 0.39 | 0.79 | 1.17 | 1.05 | 0.95 | 0.74 | 1.00 |
Testing performed at an accredited acoustical laboratory within a controlled environment using specific fabric, sizes and mounting. Therefore, ratings may vary slightly depending on customers fabric choice and mounting configuration.
